Low Temperature Operation 12V 100ah LiFePO4 Battery Pack

Product Detail

	Model	P04S100BL	P04S120BL	P04S200BL
Basic Characteristics	Nominal Voltage	12.8V	12.8V	12.8V
	Nominal Capacity	100Ah	120Ah	200Ah
	Effciency	≥96%	≥96%	≥96%
	lnner Resistance	10mΩ	10mΩ	7mΩ
	Cell Type	LiFePO4	LiFePO4	LiFePO4
Charging Characteristics	Charge Voltage	14.6V	14.6V	14.6V
	Standard Charging Current	20A	24A	40A
	Max.Continuous Charging Current	100A	100A	100A
Discharge Characteristics	Standard Discharge Current	10A	20A	40A
	Continuous Discharge Current	100A	100A	100A
	Peak Discharge Current	200A (3s)	200A (3s)	200A (3s)
	Discharge Cut-off Voltage	10v	10v	10v
Environmental Requirements	Charge Temperature Range	0~60°C	0~60°C	0~60°C
	Discharge Temperature Range	-10°C~65°C	-10°C~65°C	-10°C~65°C
	Storage Temperature Range	-5~40°C	-5~40°C	-5~40°C
	Storaqe Humidity	65±20%HR	65±20%HR	65±20%HR
Mechanical Characteristics	Size(L×W×H)/mm	330×173×215	330×173×215	521×238×218
	Package Size (L×W×H)/mm	382×222×265	382×222×265	557×292×275
	Shell Material	plastic	plastic	plastic
	Net Weight	~12.1kg	~13.8kg	~25.2kg
	Gross Weight	~13.6kg	~15.3kg	~27.2kg
	Package Method	1pcs per carton	1pcs per carton	1pcs per carton
Others Characteristics	Cycle Life	≥6000 times	≥6000 times	≥6000 times
	Self Discharge	2% per month	2% per month	2% per month
	SOC Indication	can be customized	can be customized	can be customized
	Communication Mode	can be customized	can be customized	can be customized
